Shelly 1PM Gen3
Shelly 1PM Gen3 - Image 2
Shelly 1PM Gen3 - Image 3
Shelly 1PM Gen3 - Image 4

Shelly Smart Home

Shelly 1PM Gen3

22.000 JOD

3 Years Manufacturer Warranty

Wi-Fi-operated smart switch, with power monitoring, for remote control of a wide range of home appliances and office equipment.

Request information
  • Wi-Fi-operated smart switch, with power monitoring, for remote control of a wide range of home appliances and office equipment.

Reference

Technical specifications

Every value below is sourced from the manufacturer datasheet. Engineering-first hardware, documented down to the last gram.

01

Physical

  • Size (HxWxD)
    37x42x16 mm / 1.46×1.65×0.63 in
  • Weight
    27 g / 0.95 oz
  • Screw terminals max torque
    0.4 Nm / 3.5 lbin
  • Conductor cross-section
    0.2 to 2.5 mm² / 24 to 14 AWG (solid, stranded, and bootlace ferrules)
  • Conductor stripped length
    6 to 7 mm / 0.24 to 0.28 in
  • Mounting
    Wall console / In-wall box
  • Shell material
    Plastic
  • Shell color
    Red
02

Environmental

  • Ambient working temperature
    -20°C to 40°C / -5°F to 105°F
  • Humidity
    30% to 70% RH
  • Max. altitude
    2000 m / 6562 ft
03

Electrical

  • Power supply
    110-240V~24-30V⎓
  • Power consumption
    < 1.2 W
04

Output circuits ratings

  • Max. switching voltage
    240V~30V⎓
  • Max. switching current
    16A (240V~)10A (30V⎓)
05

Sensors, meters

  • Internal-temperature sensor
    Yes
  • Voltmeter (AC)
    Yes
  • Ammeter (AC)
    Yes
06

Radio

  • Wi-Fi Protocol
    802.11 b/g/n
  • RF band
    2401-2483 МHz
  • Max. RF power
    < 20 dBm
  • Range
    Up to 50 m / 165 ft outdoors, up to 30 m / 99 ft indoors (depending on local conditions)
07

Bluetooth

  • Protocol
    4.2
  • RF band
    2400-2483.5 MHz
  • Max. RF power
    <4 dBm
  • Range
    Up to 30 m / 100 ft outdoors, up to 10 m / 33 ft indoors (depending on local conditions)
08

Microcontroller unit

  • CPU
    ESP-Shelly-C38F
  • Flash
    8 MB
09

Firmware capabilities

  • Schedules
    20
  • Webhooks (URL actions)
    20 with 5 URLs per hook
  • Wi-Fi range extender
    Yes
10

BLE Gateway Yes

  • Scripting
    Yes
  • MQTT
    Yes
  • Encryption
    Yes

Works with

Plays well with the platforms you already use.

Connect over Wi-Fi, Bluetooth, or Matter and control from any of the major ecosystems.

  • Amazon Alexa Voice
  • Google Home Voice
  • Apple Home iOS / iPadOS
  • Matter Standard
  • Home Assistant Open source
