Details
-
Size (HxWxD)
96x53x59 mm / 3.78×2.01×2.32 in -
Weight
87 g / 3 oz -
Screw terminals max torque
0.4 Nm / 3.5 lbin -
Conductor cross section
0.5 to 2.5 mm² / 20 to 14 AWG -
Conductor stripped length
6 to 7 mm / 0.24 to 0.28 in -
Mounting
DIN-rail -
Shell material
Plastic -
Shell color
Black -
Ambient working temperature
-20°C to 40°C / -5°F to 105°F -
Humidity
30% to 70% RH -
Max. altitude
2000 m / 6562 ft -
Power supply
110 – 240 VAC -
Power consumption
< 1 W -
External protection
Tripping characteristic B or C,max. 16 A max. rated current,min. 6 kA interrupting rating,energy limiting class 3
