Shelly Plus 1PM

Name: Shelly Plus 1PM
SKU: 259
Availability: InStock

16.000 JOD

3 Years Manufacturer Warranty

Wi-Fi-operated smart switch with precise power metering and free cloud data storage. Provides multiple opportunities – from automatization of the lights to electrical appliances control.

Request information

Wi-Fi-operated smart switch with precise power metering and free cloud data storage. Provides multiple opportunities – from automatization of the lights to electrical appliances control.

Reference

Technical specifications

Every value below is sourced from the manufacturer datasheet. Engineering-first hardware, documented down to the last gram.

01

POWER

Power supply AC
110-230V ±10%, 50/60Hz
Maximum load
16A
Power supply DC
24 – 30V
Channels
1 Channel

02

SPECIAL FUNCTIONS

Dry contacts
No
Roller shutter mode
No
Device temperature protection
Yes
Overload protection
Yes
Power measurement
Yes
Working without a neutral line
No

03

FEATURES

HTTP/HTTPS webhooks
Yes
Custom scripts (mJs)
Yes
Operational temperature
-20°C to + 40 °C
Device power consumption
< 1 W
Intelligent On/Off
Yes
Local and remote control
Yes
Sunrise/Sunset
Yes
Weekly Schedule
Yes
UL Listed option
No

04

CONNECTIVITY

Wireless
Yes
Wi-Fi Protocol
802.11 b/g/n
Wi-Fi Radio frequency
2412 – 2484 MHz
Wi-Fi Radio signal power
1mW
Wi-Fi Range
up to 50 m outdoors and up to 30 m indoors (depending on the building materials)
Bluetooth
Yes
