Shelly Smart Home

Shelly Plus 2PM

Name: Shelly Plus 2PM
SKU: 260
Availability: InStock

25.000 JOD

3 Years Manufacturer Warranty

One device, different possibilities: Automate lights and monitor their real-time power consumption or automate and control the current position of roller shutters, curtains, garage doors, etc.

Request information

One device, different possibilities: Automate lights and monitor their real-time power consumption or automate and control the current position of roller shutters, curtains, garage doors, etc.

Reference

Technical specifications

Every value below is sourced from the manufacturer datasheet. Engineering-first hardware, documented down to the last gram.

01

Physical

Size (HxWxD)
37x42x16 ±0.5 mm / 1.46×1.65×0.63 ±0.02 in

02

Weight:

Mounting
Wall console
Screw terminals max torque
0.4 Nm / 3.5 lbin
Conductor cross section
0.5 to 1.5 mm² / 20 to 16 AWG
Conductor stripped length
5 to 6 mm / 0.20 to 0.24 in
Shell material
Plastic
Color
Black

03

Environmental

Ambient temperature
-20 °C to 40 °C / -5 °F to 105 °F
Humidity
30 % to 70 % RH
Max. altitude
2000 m / 6562 ft

04

Electrical

Power supply
110 – 240 VAC / 24 VDC ±10%
Power consumption
< 1.4 W

05

Output circuits ratings

Max switching voltage AC
240 V
Max switching voltage DC
30 V
Max switching current AC
10 A (per channel), 16 A (total), 18 A (total peak)
Max switching current DC
10 A

06

Sensors, meters

Temperature sensor
Yes
Voltmeter (AC)
Yes
Ammeter (AC)
Yes

07

Radio

RF band
2400 – 2495 MHz
Max. RF power
<20 dBm
Wi-Fi protocol
802.11 b/g/n
Wi-Fi Range
Up to 30 m / 100 ft indoors and 50 m / 160 ft outdoors (Depends on local conditions)
Bluetooth Protocol
4.2
Bluetooth Range
Up to 10 m / 33 ft indoors and 30 m / 100 ft outdoors (Depends on local conditions)
