Shelly Smart Home

Shelly Pro 1

Name: Shelly Pro 1
SKU: 273
Availability: InStock

47.000 JOD

5 Years Manufacturer Warranty

1-phase, 1-channel relay with potential-free outputs (dry contacts), supporting up to 16A for professional lights and appliance automation for residential or commercial use.

Request information

1-phase, 1-channel relay with potential-free outputs (dry contacts), supporting up to 16A for professional lights and appliance automation for residential or commercial use.

Reference

Technical specifications

Every value below is sourced from the manufacturer datasheet. Engineering-first hardware, documented down to the last gram.

01

Physical

Size (HxWxD)
94x19x69 ±0.5 mm / 3.70×0.75×2.71 ±0.02 in
Weight
63 g / 2.22 oz.
Mounting
DIN rail
Screw terminals max torque
0.4 Nm / 3.54 lbin
Conductor cross section
0.5 to 2.5 mm² / 20 to 14 AWG (green connector) 0.5 to 1.5 mm² / 20 to 16 AWG (blue connectors)
Conductor stripped length
6 to 7 mm / 0.24 to 0.28 in (green connector) 5 to 6 mm / 0.20 to 0.24 in (blue connectors)
Shell material
Plastic
Color
Blue

02

Environmental

Ambient temperature
-20 °C to 40 °C / -5 °F to 105 °F
Humidity
30 % to 70 % RH
Max. altitude
2000 m / 6562 ft

03

Electrical

Power supply voltage AC
110 – 240 V
Power supply voltage DC
N/A
Power consumption
< 3 W
Neutral not needed
No

04

Output circuits ratings

Max switching voltage AC
240 V
Max switching voltage DC
N/A
Max switching current AC
16 A
Max switching current DC
N/A

05

Sensors, meters

Temperature sensor
Yes

06

Radio

RF band
2400 – 2495 MHz
Max. RF power
<20 dBm
Wi-Fi protocol
802.11 b/g/n
Wi-Fi Range
Up to 30 m / 100 ft indoors and 50 m / 160 ft outdoors (Depends on local conditions)
Bluetooth Protocol
4.2
Bluetooth Range
Up to 10 m / 33 ft indoors and 30 m / 100 ft outdoors (Depends on local conditions)
