PHYSICAL
-
Dimensions (LxWxH)
94x19x69 mm / 3.70×0.75×2.71 in -
Weight
75 g / 2.7 oz -
Ambient temperature
-20 °C to 40 °C / -4 °F to 104 °F -
Humidity
30 % to 70 % RH -
Max. altitude
2000 m / 6562 ft -
Screw terminals max torque
0.4 Nm / 3.5 lbin -
Conductor cross section
0.5 to 2.5 mm2 / 20 to 14 AWG (green connectors) – 0.5 to 1.5 mm2 / 20 to 16 AWG (blue connector) (solid, strand-ed, and bootlace ferrules) -
Conductor stripped length
6 to 7 mm / 0.24 to 0.28 in (green connectors) – 5 to 6 mm / 0.20 to 0.24 in (blue connector) -
Power supply
110-240 V~ 50/60 Hz -
Power consumption
< 2 W -
External protection
max. 10 A, tripping characteristic B or C,6 kA interrupting rating, energy limiting class 3
