Details
-
Power supply
230 V ±10%, 50/60 Hz -
Power consumption
< 0.7 W -
Power measurement (W)
Yes -
Max. switching voltage AC
260 V -
Max. switching current AC
13 A -
Overheating protection
Yes -
Overcurrent protection
Yes -
Overvoltage protection
Yes -
Distance
up to 40 m indoors (131 ft.) -
Z-Wave repeater
Yes -
CPU
Z-Wave S800 -
Z-Wave frequency band
868,4 MHz -
Maximum radio frequency power transmitted in frequency bend(s)
< 25 mW -
Size (H x W x D)
60 x 60 x 56 ±0.5 mm / 2.36 x 2.36 x 2.20 ±0.02 in -
Weight
74 ±1 g / 2.6 ±0.04 oz -
Compatible sockets
BS 1363 (Type-G) -
Compatible plugs
BS 1363 (Type-G) -
Shell material
Plastic -
Color
White -
Ambient temperature
-20°C to 40°C / -5°F to 105°F -
Humidity
30% to 70% RH -
Max. Altitude
2000 m / 6562 ft.
